Description
The sugar packing machine doesn’t seal the empty bags for the case of material saving. The superior cleaning device, dust removing device and intensified sealing technique ensures the dustless working environment.
Application
Sugar packaging equipment is suitable for granules such as chemicals, seasonings, natural flavoring, fertilizer, feed, granulated sugar, salt, etc.
Technical Parameters of Sugar Packing Machine
|
Capacity
|
30 to 50 bag/min, according to product type and characteristics
|
|
Bag Size
|
(L): 100 to 300mm (W): 100 to 200 mm
|
|
Filling weight
|
Up to1000 g/bag (max)
|
|
Bag sealing
|
Sealing by heat and pressure
|
|
Power supply
|
AC380V ±10%, 3-phase, 50Hz
|
|
Power Consumption
|
2.0 kW
|
|
Air consumption of sugar packing machine
|
0.2 m3/min at 5 to 8 kgf/ cm2 Air compressor is supplied by customer
|
|
Machine Weight
|
1200 kg
|
|
Dimension of sugar packaging equipment
|
W×L×H: 1140 × 1500 × 1560 mm
|
